Live Clear Guide

Live Clear Guide

Description

LIVE ROLLERS

Article

-

General Characteristics

Excellent performance with K13 guide. High tensile strength with kevlar cords.

Print Data sheet
Request Sample

Technical Information

Standar Width
3 in 77 mm
Total Thickness
0.39 in 10 mm
Mass
1.09 lb/ft2 4.80 kg/m2
Breaking Point
3,407 lbf 15,1550 N
Breaking Point PIW
1,156 lbf/in 202 N/mm
Max Allowed Load
867 lbf 3,856 N
Max Allowed Load PIW
289 lbf/in 50.60 N/mm
Working Temp.
-22/+190 F -30/+90 C
Flexion (A)
3.15 in 80 mm
AB Belt Schema
Counter Flexion (B)
N/A N/A
Coefficient of friction
Bottom side - Steel
0.60

Special Features

Antistatic
Fray-less
Live Clear Guide Live Clear Guide

Top side (Carrying)

Material
PU
Color
Clear
Hardness
90 Shore A | DIN53505

Tension member

Cords
Kevlar Cords

Bottom side (Pulley)

Material
PU
Color
Transparent
Guide
K13
Hardness
90 Shore A | DIN53505
Surface
Smooth
wave horizontal addon

Splice Instructions

Finger splice
Preferred method
Finger splice


  • Splice Type Finger Splice (5 to 10 inches)
  • Pressure 2 BARS | 29 PSI
  • Top/Bottom Temp. 180˚C | 350 F
  • Dwell Time 4 Minutes
  • Cool Down 70˚C | 160 F
  • Recommended Press Small Air-Cooled Press (Flexco Novitool® AERO® 325)
