Novo 25 Black

Novo 25 Black

General Characteristics

Needled polyester black, rubber impregnated. Highly conductive ( highly antistatic). 2.5mm thick.

Technical Information

Fiber
Felt Felt
Plies
1 1
Thickness
in to in mm to mm
Density
lbs/in3 grs/cm3
Pull per 1 %
85.50 lbf/in 15.00 dan/cm
Operating temp
248 F 120 C
Flexion (A)
0.79 in 20.00 mm
Counter Flexion (B)
0.79 in 20.00 mm
Weave
Color
Black

Special Features

Antistatic ISO 284 & 21178
Oil & Fat Resistant
Novo 25 Black
Novo 25 Black

Recommended Uses

Slider Bed

Slider Bed

Flat Rollers

Flat Rollers

Slider Beds on Both sides

Slider Beds on Both sides

Channel Trough

Channel Trough

Conventional Trough

Conventional Trough

Incline Conveying

Incline Conveying

Incline Variation

Incline Variation

Bucket Elevator

Bucket Elevator

Conveyor with Accumulation

Conveyor with Accumulation

Bend Conveyor

Knife Edge Conveyor

Knife Edge Conveyor

  • Applicable

  • Limited use

  • Not Applicable
